Description
The NEFF U1ACE2AN3B N50 is a stainless steel built-in electric double oven with a 71L main CircoTherm oven, 34L secondary oven, LCD display, EasyClean cleaning assistance and electric grills in both cavities.
Product Description
NEFF N50 Built-In Double Oven
The NEFF U1ACE2AN3B is a 59.4cm built-in electric double oven from the NEFF N50 range. Its two cavities provide 71L of main oven capacity and 34L in the secondary oven, giving a combined usable capacity of 105 litres.
The stainless-steel appliance is designed for installation under a worktop and measures 888mm high × 594mm wide × 550mm deep.
CircoTherm® Main Oven
The main oven features NEFF’s CircoTherm® hot-air technology, designed to distribute heat around the cavity for even cooking across multiple levels.
The main cavity has 5 cooking functions, including CircoTherm® hot air, CircoTherm® Gentle, conventional heat, hot-air grilling and full-width grilling.
Secondary Oven and Grill
The 34L secondary cavity provides four cooking functions, including conventional heat, bottom heat, full-width grill and half-width grill.
This makes the double oven suitable for cooking different dishes simultaneously at different temperatures.
LCD Display and Electronic Controls
The U1ACE2AN3B uses a white LCD display with electronic controls and retractable control dials. The display provides temperature and timer information while keeping operation straightforward.
EasyClean® Cleaning Assistance
The oven does not have an integrated pyrolytic cleaning system. Instead, NEFF provides EasyClean® cleaning assistance, designed to help soften and loosen light cooking residue for easier manual cleaning.
Built-Under Installation
The oven is designed to fit beneath a worktop and requires an installation aperture of approximately 875–888mm high × 560–568mm wide × 550mm deep. Electrical connection is fixed and must be carried out by an electrician.
Key Features
- NEFF N50 built-in double oven
- Model U1ACE2AN3B
- Stainless steel finish
- 71L main oven
- 34L secondary oven
- 105L combined capacity
- CircoTherm® main oven
- 5 main-oven cooking functions
- 4 secondary-oven cooking functions
- Full-width electric grill
- Half-width grill
- Conventional heat
- Hot-air grilling
- CircoTherm® Gentle
- EasyClean® cleaning assistance
- White LCD display
- Retractable electronic controls
- Interior lighting in both cavities
- 4 shelf positions in main oven
- 3 shelf positions in second oven
- Child/control panel lock
- Double-glazed doors
- Removable inner door glass
- A energy rating for main cavity
- B energy rating for secondary cavity
- No Home Connect
- No integrated pyrolytic cleaning
- Built-under installation
Technical Specifications
| Attribute | Specification |
|---|---|
| Brand | NEFF |
| Range | N50 |
| Model | U1ACE2AN3B |
| MPN | U1ACE2AN3B |
| GTIN / EAN-13 | 4242004281771 |
| Product Type | Built-In Electric Double Oven |
| Finish | Stainless Steel |
| Number of Cavities | 2 |
| Main Oven Capacity | 71L |
| Second Oven Capacity | 34L |
| Combined Capacity | 105L |
| Main Energy Rating | A |
| Second Energy Rating | B |
| Main Cooking Functions | 5 |
| Second Oven Functions | 4 |
| Main Oven Technology | CircoTherm® |
| Main Temperature Range | 50–275°C |
| Display | White LCD |
| Controls | Electronic / Retractable Dials |
| Cleaning | EasyClean® |
| Pyrolytic Cleaning | No |
| Home Connect | No |
| Main Shelf Positions | 4 |
| Second Oven Shelf Positions | 3 |
| Main Interior Light | 25W Halogen |
| Second Interior Light | 25W Halogen |
| Door Glazing | Double Glazed |
| Removable Inner Glass | Yes |
| Connection Rating | 5.9kW |
| Fuse Protection | 32A |
| Voltage | 220–240V |
| Frequency | 50Hz |
| Plug | No plug; fixed electrical connection |
| Appliance Dimensions H × W × D | 888 × 594 × 550mm |
| Packed Dimensions H × W × D | 960 × 660 × 690mm |
| Net Weight | 49.4kg |
NEFF’s manufacturer specification confirms the 71L/34L capacities, A/B energy classes, 5/4 cooking functions, 5.9kW connection rating, 32A fuse, dimensions and 49.4kg net weight.
Cooking Functions
Main Oven – 5 Functions
- Full-width grill
- CircoTherm® Gentle
- CircoTherm® / Hot Air
- Conventional heat
- Hot-air grilling
Second Oven – 4 Functions
- Full-width grill
- Half-width grill
- Conventional heat
- Bottom heat
NEFF’s 2026 range brochure specifically identifies the U1ACE2AN3B as an N50 with 5 main-oven functions and 4 second-oven functions.
Cleaning
EasyClean®: Yes
Integrated cleaning system: No
Pyrolytic cleaning: No
Catalytic liners: No integrated catalytic cleaning system specified
EasyClean is intended as a cleaning aid rather than a self-cleaning pyrolytic system.
Included Accessories
- 3 × combination grids
- 1 × universal pan
